Double face in situ concrete barrier BHDEG0/0a-H1W1

Permanent Vehicle Restraint System

Parameters of behaviour according to UNE-EN 1317-2

Containment level:H1
Normalized work width level:0,6 m (W1)
Maximum dynamic deflection:0 m
Impact serverity level:B
Normalized vehicle intrusion level1,8 m (VI5)

Initial type test

LaboratoriesType of impact test
APPLUS IDIADATB11 – A201017ALGS
CIDAUTTB42 – E19-1734

Type and characterization of materials:

Concrete:HA-30/P/I/F
ArmorB 500 SD
Resistance to snow removal:Class 4
Terrain type:On a layer of bituminous firm or concrete
Parts detached:They do not detach
Conditions of durability (materials and coatings):XF4 exposure class according to UNE-EN 206-1
Manufacturing Procedure:According to Installation Manual
