New cover of double face in situ concrete barrierBARCOV-S-H2W1
Permanent Vehicle Restraint System
Parameters of behaviour according to UNE-EN 1317-2
| Containment level: | H2 |
| Normalized work width level: | 0,6 m (W1) |
| Maximum dynamic deflection: | 0 m |
| Impact serverity level: | B |
| Normalized vehicle intrusion level | 1,5 m (VI5) |
Type and characterization of materials:
| New layer Concrete: | HA-30/P/20/I+F |
| New Jersey Concrete: | C20/25 |
| Resistance to snow removal: | Class 4 |
| Terrain type: | On a layer with bituminous firm or concrete. |
| Conditions of durability (materials and coatings): | XF4 exposure class according to EN 206-1 |
| Manufacturing Procedure: | According to Installation Manual |
