Double face in situ concrete barrier BHDEG0/0a-H2W2R
Permanent Vehicle Restraint System
Parameters of behaviour according to EN 1317-2
| Containtment level | H2 |
| Normalized work width level: | 0,7 m (W2) |
| Maximum dynamic deflection: | 0 m |
| Impact severity level: | B |
| Normalized vehicle intrusion level: | 0,5 m (VI1) |
Type and characterization of materials:
| Concrete: | HA-30/P/I/F |
| Armor: | B 500 SD |
| Resistance to snow removal: | Class 4 |
| Terrain type: | On a layer with minimum thickness of 15cm of bituminous firm or concrete |
| Parts detached: | They do not detach |
| Conditions of dubrabiliy (materials and coatings): | XF4 exposure class according to EN 206-1 |
| Manufacturing procedure: | According to installation manual |
